Molbank 2006, M465

http://www.mdpi.net/molbank/



New bis-tridentate Nitrogen Ligand : N,N,N',N'-tetra-(3-carbomethoxy-5-methylpyrazol-1-ylmethyl)p-phenylenediamine



Maria DAOUDI,a Brahim BENNANI,a Assou ZAHIDI,b Mohamed MCHICH,b Taibi BEN HADDAb,*



a Laboratoire de Chimie Organique, Facult¨¦ des Sciences Dhar El Mehraz, 50000 F¨¨s, Morocco.

b Laboratoire d¡¯Activation Mol¨¦culaire, Facult¨¦ des Sciences, 60000 Oujda, Morocco.

e-mail: [email protected]



Received: 15 July 2005 / Accepted: 6 September 2005 / Published: 28 February 2006



Keywords: bis-tridentate ligand - Pyrazole - Amine/ alcohol condensation - Electronic Communication.





The product 2 was prepared by the addition of p-phenylendiamine (NH2C6H4NH2) to 1 [1] according to the reported procedure [2]. To a solution of 1 (3.4 g, 20 mmol) in acetonitrile (45 ml) was added p-phenylendiamine (0.54 g, 5 mmol) and the mixture was stirred. The stirring was continued at room temperature for a week. The residue was precipitated by addition of cold water, purified and dried by hexane and under vacuum, to afford 2.63 g (74% yield) 2 as a white solid.



Melting Point: 197 ¡ãC.



IR (KBr, cm¨C1): 3140 (=CH), 2990 (CH), 1730 (C=O), 1540 (C=C), 1480 (-C=N), 1450, 1410.



1H-NMR (400 MHz, CDCl3): ¦Ä= 7.25 (s, 4H, Ph); 6.5 (s, 4H, Pyrazol); 5.6 (s, 8H, N-CH2-N); 4 (s, 12H, O-CH3); 2.2 (s, 12H, CH3).



MS (m/z): 739 [M + Na+]; 716  [M]+; 613; 585; 460.



Acknowledgment:

We are indebted to the "Programme Th¨¦matique d'Appui ¨¤ la Recherche Scientifique PROTARS N¡ã P1T2/27", and the "Wylaya d'Oujda" for financial support.



References:

1. Dvoretzky, I.; Richter, G.H., J.Org.Chem., 1950, 15, 1285.

2. Sheu, S-C; Tien, M-J.; Cheng, M-C.; Ho, T-I.; Peng, S-M. And Lin, Y-C., J. Chem. Soc. Dalton Trans, 1995, 3503-3510.



Sample Availability: Available from the authors and MDPI.
