Molbank 2006, M473

http://www.mdpi.net/molbank/



1-ethoxycarbonylmethyl-3-(ethoxycarbonylmethylene)-2-oxo quinoxaline



Souad Ferfra, Noureddine H.Ahabchane and El Mokhtar Essassi*



Laboratoire de Chimie Organique H¨¦t¨¦rocyclique, Facult¨¦ des Sciences, BP 1014, Avenue Ibn Batouta, Rabat, Maroc

e-mail:  [email protected]

*Author to whom correspondence should be addressed



Received: 13 February 2006 / Accepted: 18 February 2006/ Published: 28 February 2006



Keywords: quinoxaline, phase transfer catalysis, alkylation







The compound 3, which exists in tautomeric equilibria between enamine (form A) and methylene imine (form B), was prepared by addition of ethoxycarbonylmethyl chloride 2 (1.23g, 0.01 mol) to a solution of 3-(ethoxycarbonylmethylene)-2-oxo quinoxaline, 1 [1] (2.32 g, 0.01 mol) in 60 ml DMF, K2CO3 (1.38g, 0.01mol) and triethylbenzylammonium chloride (0.001 mol).  The mixture was stirred for 24 hours at room temperature. After filtration, the solvent was evaporated and the residue was recrystallized from ethanol affording 3 in 90% yield.



Melting point: 154-156¡ãC.



IR (KBr, cm-1) : 1650 ( nN-C=O); 1720 (nN-C=O).



1H-NMR (250 MHz, CDCl3): ¦Ä= 11.20 (0.5H, s, NH, form A); 7.87-6.82 (8H, m, ar); 5.83 (0.5H, s, =CH, form A); 5.01 (1H, s, NCH2); 4.89 (1H, s, NCH2); 4.21 (8H, m, CH2); 3.95 (2H, s, CH2, form B); 1.27 (12H , m, CH3).



13C-NMR (250MHz, CDCl3): ¦Ä= 170.7 (Cq); 169.3 (Cq); 167.3 (Cq);  166.9 (Cq); 156.4 (Cq); 154.4 (Cq); 142.5 (Cq); 132.7 (Cq); 130.6 (CHar); 130.4 (CHar); 126.0 (Cq); 124.5 (CHar); 124.0 (CHar); 122.5 (CHar); 115.4 (CHar); 113.8 (CHar); 113.2 (CHar); 86.7 (=CH form A);  62.1 (CH2); 62.0 (CH2); 62.2 (CH2); 59.9 (CH2); 44.0 (NCH2); 43.6 (NCH2); 40.7 (CH2 form B); 14.4 (CH3); 14.1 (CH3).



MS (I.E): 318 [M+].



Reference

1. Kurasawa, Y. and Takada, A.; Heterocycles, 1985, 23, N¡ã8



Sample Availability: Available from MDPI.
