Molbank 2006, M498

http://www.mdpi.org/molbank/



(4Z)-1-Propargyl(1,3-Dipropargyl)-4-(2-oxopropylidene)-1,3,4,5-tetrahydro-2H-1,5-benzodiazepin-2-one



Ould Mohamed Sidya Mohamed Said,1 Bouhfid Rachid,1 Nicolas Joly,2 Vincent Lequart,2 Patrick Martin,2 M. Massoui1 and El Mokhtar.Essassi1*



1 Laboratoire de Chimie Organique Hétérocyclique , Faculté des Sciences, Avenue Ibn-Batouta, Rabat, Maroc.

2 Blood-Brain Barrier Laboratory (EA 2465), IUT of Béthune, University of Artois, BP 819, F-62408 Béthune

E-mail : [email protected]

*Author to whom correspondence should be addressed



Received: 18 July 2006 / Accepted: 20 July 2006 / Published: 1 September 2006



Keywords: alkylation, benzodiazepinones, propargyl bromid.



We describe in this work the synthesis of new benzodiazepine derivatives susceptible to possess various pharmacological activities.
























To a solution of (4Z) -2-oxopropylidene-1,5-benzodiazepin-2-one 1[1,2] (0,01 mole, 2,16 gm  in tetrahydrofuran 60 mL, was added K2CO3 (0.02mole, 2,76 gm), propargylbromid (0,02 mole, 2,36 gm) and tetra n-butylammonium bromid TBAB (0,001 mole, 0,321 gm). The mixture was stirred at room temperature for 48 hours. The solution was filtered by suction filtration. The solvent was removed under reduced pressure. The residue was chromatographed on silica gel column using hexane and ethyl acetate (80/20) as eluent to afford the products 2a and 2b as white solids.



(4Z)-1-Propargyl-4-(2-oxopropylidene)-1,3,4,5-tetrahydro-2H-1,5-benzodiazepin-2-one, 2a

This compound was obtained in 50% yield;



Melting Point: 172-174 °C



1H-NMR (250 MHz, CDCl3): δ= 2.1 (s,3H,CH3),2.3(t,1H,4J=2.4 Hz, ), 3.1(HAHB, J=11.8 Hz, ), 4.7(HAHB, 2J=17.17 Hz, 4J=2.4 Hz,  ), 5.3(s,1H, ),7.1-7.3(m, 4H, HArom)



13C-NMR (62.9 MHz, CDCl3): δ= 29.4, 38.5, 41.2, 72.5, 79.0,  96.6,122.6, 123.2, 125.6, 126.7, 132.4,  134.5, 155.0, 166.7, 198.1



Elemental analysis: Calculated for C15H14N2O2 : C, 70.85 %; H, 5.55 %; N, 11.02 %; Found: C, 70.67 %; H, 5.46 %; N, 11.13 %;



(4Z)-1,3-Dipropargyl)-4-(2-oxopropylidene)-1,3,4,5-tetrahydro-2H-1,5-benzodiazepin-2-one, 2b

This compound was obtained in 25% yield;



Melting Point: 173-176 °C



1H-NMR (250 MHz, CDCl3): δ= 1.9(t, 1H, 4J=2.6 Hz, ), 2.1 (s,3H,CH3), 2.3 (t,1H, 4J=2.4 Hz, ), 3.3 (t, 1H, 4J=7 Hz, ), 4.2(HAHB, 2J =17.4 Hz,  ),4.7 (d,2H,2J=2.5 Hz, ),5.21(s,1H, ),7.1-7.3(m,4H, HArom), 12.6(s,1H,NH).



13C-NMR (62.9 MHz, CDCl3): δ= 16.0, 29.9,  38.6, 44.7, 93.5 122.7, 123.3, 125.8, 125.8, 127.0,131.9  134.2, 156.2,  166.9, 198.1



Elemental analysis: Calculated for C18H16N2O2: C, 73.95 %; H, 5.52 %; N, 9.58 %; Found: C, 73.82 %; H, 5.58 %; N, 9.66 %;



References:

1. El Abbassi M., Essassi E.M. and.Fifani J.; Tetrahedron Lett, 1987, 28, 1389.

2. Djerrari B., El Abbassi M., Essassi E.M. and Fifani J.; Tetrahedron Lett., 1989, 30, 7069.
