Molbank 2004

Molbank 2004, M363

http://www.mdpi.net/molbank/

Ethyl 6-formyl-8-methoxy-2-oxo-2H-chromene-4-carboxylate

Abdullah Mohamed Asiri

Chemistry Department, Faculty of Science, King Abdul-Aziz University, Jeddah 21413, P.O. Box 9028, Saudi Arabia.

Tel.(+966)-2-6952293, Fax (+966)-2-6952293, E-mail: [email protected]

Received: 13 September 2003 / Accepted: 4 February 2004 / Published: 24 February 2004

A mixture of vanillin 1 ( 0.5g, 3.3mmol) and triphenylphosphine ( 0.86g, 3.3mmol) was dissolved in CH₂Cl_2.The reaction mixture was cooled in ice bath to -5 ºC. Dimethylacetylenedicarboxylate 2 ( 0.56g, 3.3mmol) in CH₂Cl₂ was added dropwise over a period of 10 min under stirring. The reaction mixture was then refluxed for 4-5 hours, the solvent was removed under reduced pressure and the solid mass was purified by recrystallization from ethanol to give the desired product as yellow crystals ( 0.45g, 50%).

M.p. 118 ^оC ( recrystallized from EtOH, uncorrected).

UV l_max(nm; EtOH)/e (dm³.mol^-1.cm^-1) 335/15875

IR (cm^-1, KBr) 2980, 2863 (C-H, aldehydic), 1725 (C=O), 1600 (C=C).

¹H-NMR (400 MHz; CDCl₃; Me₄Si) d_H 9.99 (s, 1H, CHO), 8.44 ( d, 1H, J = 1.3 Hz, H-3), 7.62 ( d, 1H, J= 1.3 Hz, H-5), 7.08 (s, 1H, H-7), 4.5 (q, 2H, J = 7.0 Hz, CH₂O), 4.02 (s, 3H, CH₃O), 1.47 (t, 3H, J = 7.0 Hz, CH₃).

¹³C-NMR (100 MHz; CDCl₃; Me₄Si) d 13.85, 56.22, 62.67, 110.33 , 116.29, 120.26, 123.33, 128.19, 132.44, 141.67, 147.83, 158.31, 163.02, 190.31.

Anal.Calc. for C₁₄H₁₂O₆ ( 276.241): C 60.87, H 4.38; found : C 60.61, H 4.23.

References

1- Y. Issa, H-S. Rahim and Z. Afsaneh, Tetrahedron Letters , 1998, 39 (16), 2391-2392.

2- J. R Johnson., Org. Reaction, 1942, Vol. 1, 210-265.
