Synthesis of {3,4-bis-[(2-hydroxy-3-methoxy benzylidene)amino] phenyl}phenyl methanone as a new salen derivative

A. A. jarrahpour*, M. Zarei

Department of Chemistry, College of Sciences, Shiraz University, Shiraz 71454, Iran Tel.  0098 711 2284822,  Fax: 0098 711 2280926

E-mail: [email protected],  [email protected]

Received: 31 January 2004 / Accepted: 18 February 2004 / Published: 24 February 2004

Keywords: Schiff base, 3,4-diamino benzophenone, o-vanillin, biological activity, salen.

Benzophenone derivatives are reported to show biological activities such as cytotoxic activities against human oral squarnous carcinoma cells (HSC-2) and normal human gingival fibroblasts (HGF) [1], antibiotic activities against methicillin-resistant Staphylococcus aureus and vancomycin-resistant Enterococcus faecium [2] and protein kinase C inhibitor [3]. Boyd and coworkers have reported a benzophenone derivative exhibited activity in the primary anti-HIV screen [4]. Schiff bases are widely in use for synthetic purposes both by organic and inorganic chemists [5]. In addition, Schiff bases show biological activities including antibacterial [6-7], antifungal [8-9], antitumor [10-11] and herbicidal [12] activities. Schiff bases are also used as ligand for complex formation of some metal ions [13]. Metal-salen complexes are used as catalysis in epoxidation of alkenes [14], asymmetric cyclopropanation [15] and highly selective PVC membrane sensors for the sulfate ion [16]. The mentioned properties prompted us to synthesize Schiff base 3. The biological and analytical uses of Schiff base 3 are under study.

To stirred solution of o-vanillin 2 (0.85 g, 5.64 mmol) in dry dichloromethane (40.00 mL) at 0 ^oC were successively added 3,4-diamino benzophenone 1 (0.60 g, 2.82 mmol) and a large excces of anhydrous MgSO₄ (2.00 g, 16.67 mmol). The resulting mixture was stirred for 8 hours at room temperature. The filtered solution was evaporated under reduced pressure to yield the crude Schiff base [17] which was recrystalized from ethanol 95% to give the pure Schiff base 3 as an orange solid (1.13 g, 83%).

m.p. 150-152 ^oC

IR (KBr) (cm^-1): 1612.4 (C=N), 1678.7 (C=O), 3170.8-3656.8 (OH).

¹H-NMR (CDCl₃) (250 MHz)(ppm): 3.79 (6H, s, 2OMe), 6.70-7.96 (14H, m, aryl hydrogens), 8.53 (2H, s, 2HC=N), 12.84 (2H, br, 2 OH).

¹³C-NMR (CDCl₃ ) (62.90 MHz)(ppm): 56.43 (OMe), 109.71-152.15 (aromatic carbons), 165.74 (HC=N), 197.04 (C=O).

MS (m/z, %): 480 (M⁺, 9.9), 344 (C₆H₅COC₆H₃N=CC₆H₃OHOMeN, 70.6), 239 (C₆H₃N=CC₆H₃OH OMeN, 4.6), 221 (C₆H₅COC₆H₃N=CH₂N, 5.0), 180 (C₆H₅COC₆H₃, 3.2), 123 (C₆H₃OHOMe, 11.5), 105 (C₆H₅CO, 95.0), 77 (C₆H₅ , 100.0).

Acknowledgment

The authors thank the Shiraz University Research Council for financial support (Grant No. 81-SC-1540-C220 ).

References

1.   Hou, A.-J.; Fukai, T.; Shimazaki, M.; Sakagami , H.; Sun, H.-D.; Nomura, T. J.Nat.Prod. 2001, 64,

      65-70.

2.   Cueto, M.; Jensen, P. R.; Kauuffman, C.; Fenical, W.; Lobkovsky, E.; Clardy, J. J. Nat. Prod. 2001, 64, 1444-1446.

3.   Storm, J. P.; Andersson, C.-M. Org. Lett. 1999, 1(9), 1451-1453.

4.   Boyd, M. R.; Fuller, R. W.; Westergaard, C. K.; Collines, J. W.; Cardllina II, J.H. J. Nat. Prod. 1999, 62, 67-69.

5.   Arora, K.; Gupta, A.; Agarwal, D.D. Asian J. Chem. 2002, 14 ,1611-1615.

6.   Saravanan, J.; Mohan, S. Asian J. Chem. 2003, 15, 67-70.

7.   Pandeya, S. N.; Sriram, D.; Nath, G.; De Clercq, E. IL Farmaco 1999, 54, 624-628.

8.   Berad, B.N.; Deshmukh, M.R.S.; Bhaskar, C.S. Asian J. Chem. 2002, 14 , 1241-1245.

9.   Krishnaiah, Y.S.R.; Lakashmi, M.; Satyanarayana, V.; Bhashkar, P. Asian J. Chem. 2002, 14, 1246-1250.

10. Hodnett, E. M. and  Dunn, W. J. J. Med. Chem. 1970, 13, 768-770.

11. Nofal, Z. M.; El-Zahar, M. I.; Abd El-Karim, S. S. Molecules 2000, 5, 99-113.

12. Samadhiya, S.; Halve, A. Orient. J. Chem. 2001, 17 (1), 119-122.

13. Tai, X.; Yin, X.; Chen, Q. and Tan, M. Molecules 2003, 8, 439-443.

14. Abashkin, Y. G.; Burt, S. K. Org. Lett. 2004, 6(1), 59-62.

15. Nguyen, S. B. T.; Miller, J. A.; Hennessy, E.J.; Marshall, W. J.; Scialdone, M.A.  J. Org. Chem. 2003, 68, 7884-7886.

16. Shamsipur, M.; Yousefi, M.; Hosseini, M.; Ganjali, M. R.; Shargi, H.; Naeimi, H. Anal. Chem. 2001, 73, 2869-2874.

17. Matsui, S.; Hashimoto, Y.; Saigo, K. Synthesis 1998, 1161-1166.

Sample Availability : Available from  MDPI.

© 2004 MDPI. All rights reserved
