Molbank 2005, M400

http://www.mdpi.net/molbank/



Synthesis of 4-chloro-2-(thiomorpholin-4-ylmethyl)phenol



A. Ma. Vel¨¢zquez1, L.Torres1, R.Gonz¨¢lez1, A.Valencia1, A.Pecina1, I.Menconi1,  I.Mart¨ªnez1, L.Mart¨ªnez1, A.Ram¨ªrez1, R.Hern¨¢ndez1, R.L¨®pez-Castañares2 , O.Olvera-Neria3, E.Angeles*1,



1) Facultad de Estudios Superiores Cuautitl¨¢n, Universidad Nacional Aut¨®noma de M¨¦xico,

2) Facultad de Qu¨ªmica de la UAEM,

3) Instituto de Ciencias B¨¢sicas e Ingenieria, Universidad Aut¨®noma del Estado de Hidalgo



e-mail: [email protected]



Received: 2 April 2004 / Accepted: 31 May 2004 / Published: 1 July 2005



Keywords: phenol, thiomorpholine





4-chloro-2-(thiomorpholin-4-ylmethyl)phenol (2) was prepared from 4-chlorophenol (1) and thiomorpholine and formaldehyde (37%) in methanol as solvent . A solution of methanol (50 mL) and 4-chlorophenol 1 (1.26g, 9.80 mmol)  was prepared and heated at 40 ¡ãC for 15 minutes, after that  a solution of thiomorfoline (2.0g,  20.7 mmol) and formaldehyde (1.5 mL, 20.15 mmol) in methanol was added . When the addition was completed, the reaction mixture was stirred at reflux for 24 hrs. The solvent was eliminated using rotavapor and reaction mixture was poured into water and extracted with ehtyl acetate. The product was crystallized after eliminated solvent and recrystallized from ethanol as white powder (2) (25% yield).



Melting Point: 127-129 ¡ãC (methanol, uncorrected).



IR (CHCl3 film, cm-1): 3502 (O-H); 3010 (Csp2-H Ar); 2985 (Csp3-H).



1H-NMR (300 MHz; CDCl3): ¦Ä= 10.56 (1H, s, OH); 7.11 (1H, dd, J= 8.7Hz, 2.7Hz); 6.94 (1H, d, J= 2.7Hz); 6.74 (1H, d, 8.7Hz); 3.65 (2H, s, Ar-CH2); 2.81 (4H, m, -S-CH2-); 2.71 (4H, m, -N-CH2-).



13C-NMR (75 MHz; CDCl3): ¦Ä= 156 (C); 128.56 (CH); 128.31 (CH); 123.61 (C); 122.11(C); 117.37 (CH); 61.63 (Ar-CH2); 54.27 (-S-CH2-); 27.73 (-N-CH2-).



MS (FAB; m/z, %): 244(100%); 215; 180; 154.



Elemental Analysis: Calculated for C11H14NOSCl: C, 54.20%;  H, 5.79%;  N, 5.75%;  O, 6.56%; S, 13.15%; Cl, 14.54%. Found: C, 54.40%; H, 5.77%; N, 5.80%; O, 6.45%; S, 13.22%; Cl, 14.49%.



Acknowledgements

The authors wish to acknowledge to PAPIIT/UNAM Projects No IN205902 and IN207705 and ALPHARMA SA de CV, by partially support this work. We would like to thank C.Barajas, F.Sotres, P.Garc¨ªa, D.Jim¨¦nez from FESC-UNAM and Rosa I.del Villar M., Oscar Yañez and Georgina Duarte from USAI-UNAM for their skillful technical assistance and DGSCA-UNAM for their support. As a part of Project C¨¢tedra Qu¨ªmica Medicinal of FESC-UNAM.



References

1. Biava, M., Fioravanti, R., Porretta, G.C., Deidda, D., Maullu, C., Pompei M. Biorg.& Med.Chem.Lett. 1999, 9, 2083-2985.

2. Teipel, S.; Griesar, K.; Haase, W.; Krebs, B. Inorganic Chemistry  1994,  33,  456-64.

3. Hodgkin, J.H., Aust .J. Chem., 1984, 37, 2371-2378.
