Molbank 2005, M402

http://www.mdpi.net/molbank/



5-Ferrocnylidene(1,3-diethylthiobarbituric acid)



Abdullah Mohamed Asiri



Chemistry Department, Faculty of Science, King Abdul-Aziz University,

Jeddah 21413, P.O. Box 9028, Saudi Arabia.

Tel. (+966)-2-6952293, Fax (+966)-2-6952293, e-mail: [email protected]



Received: 8 April 2004 / Accepted: 20 April 2004 / Published: 1 July 2005



Key Word: ferrocen, knovenagel condensation, dyes



There is considerable interest in the synthesis of new materials with large second-order optical non-linearity because of their potential applications in optical data storage, telecommunications and optical signals processing 1-4. First and second hyperpolarizability can be observed with molecules which possess an electron donor and acceptor groups connected by a conjugated ¦°-electron bridge which allow the possibility of intramolecular charge transfer 5-6.





To a refluxed solution of ferrocenecarboxaldehyde 1 (2.0g, 9.34 mmol) and N,N-diethylthiobarbituric acid 2 (1.87g, 9.34 mmol) in ethanol (50 ml), Piperidine (1 ml) was added. After the addition, the solution became darker and the reflux was continued for six hours, then the solution was left to cool to room temperature and the product 3 was precipitated. The precipitates were filter and washed with cold water and finally with ethanol, dried and recrystallized from ethanol. Deep blue crystal (3g, 81.01%).



Melting point: 164-166 §àC (uncorrected).



UV (EtOH; ¦Ëmax  nm; ¦Å (dm3.mol-1.cm-1): 374 (16521); 575 (3700).



IR (KBr, cm-1): 1680, 1660 (C=O); 1620 (C=C); 1115 (C=S); 1101, 992, 809.



1H-NMR (400 MHz; CDCl3): ¦Ä= 8.46 (1H, s, -CH=C); 5.36 (2H, broad s, H-2, H4, H-5); 4.97 (2H, broad s, H-2, H3, H-4); 4.31 (5H, s, C5H5); 4.31 (4H, q, CH2N); 1.32 (6H, t, CH3CH2N).



Elemental Analysis: Calculated for C19H20N2O2SFe (396.19): C, 57.57%; H, 5.05%; N, 7.07%: Found; C, 57.36%; H, 4.88%; N, 7.14%



References

1. R. W. Boyd ,Nonlinear Optics, academic Press, New York, 1992.

2.  S. R.  Marder, Beratan DN, Cheng LT. Science. 1991, 252(103).

3. D. F. Eaton, Science. 1991, 253(281).

4. E. G. Staring. Recl. Trav. Chim. Pas-Bas. 1991, 110( 492).

5. C. W.  Derik, R. J.  Wagniere. J. Am. Chem. Soc. 1986, 5387 (108).
