Molbank 2008, M578

molbank

ISSN 1422-8599

www.mdpi.org/molbank

Short Note

Synthesis and Characterization of N,N’-(propane-1,2 diyldicarbamothioyl)dibenzamide

Gülşah Kurt * and Bedrettin Mercimek

Department of Chemistry, Faculty of Education, Selcuk University, Meram 42099 Konya, Turkey

* Author to whom correspondence should be addressed; E-Mail: [email protected]

Tel. +90 332 8220; Fax: +90 332 323 82 25

Received: 9 September 2008 / Accepted: 3 November 2008 / Published: 7 November 2008

Keywords: Benzoylthiourea, benzoyl isothiocyanate, amine.

Benzoylthioureas have found some interest due to their biological activity [1], spectroscopic and structural properties [2,3], or as synthetic building blocks [4]. Here, we report the convenient preparation of a new representative of this type of compounds. Benzoyl isothiocyanate (1) was prepared by known methods reported in the literature [5]. Benzoyl isothiocyanate (21 ml) was added to a solution of 1,2-diaminopropane (17 ml) in anhydrous acetone. The resulting mixture was refluxed for 6 h. Finally, the mixture was cooled in an ice bath and 1M HCl (250 ml) was added. The yellow precipitate was collected by filtration and it was washed with diethyl ether. The title compound 2 thus obtained was recrystallized from EtOH/CH₂Cl₂.

Scheme 1. ¹H NMR spectrum of 2.

Color: yellow.

Mp 162-163°C.

Elemental analysis: Found: C, 57.5; H, 5.1; N, 13.9; S, 16.0. Calc. for C₁₉H₂₀N₄S₂O₂: C, 57.0; H, 5.0; N, 14.0; S, 16.0.

¹H NMR: δ (CDCl₃, 400.1 MHz): 11.00 (s, 1H, NH-CO); 10.96 (d, 1H, NH-CO); 9.04 (s, 1H, NH); 8.99 (s, 1H, NH); 7.84–7. 52 (m, 10H, PhH); 5.03–4.98 (m, 1H, CH); 4.19–3.99 (m, 2H, CH₂); 1,46–1,44 (d, 3H, CH₃).

¹³C NMR: δ (CDCl₃, 100.0 MHz): 185.2 (C=S); 164.0 (C=O); 135.6–127.2 (C=C_arom);

47.5 (CH); 46.9 (CH₂); 18.7 (CH₃).

.

IR (KBr) ν_max/cm^-1: 3350–3300 (N-H), 3161 (C-H_aromatic), 3038 (CH₃), 2935–2859 (C-H_aliphatic), 1980–1835 (C=C), 1677 (C=O), 1540–1258 (C-N), 1189, 1162 (C=S).

UV-vis (CH₂Cl₂, abs): 240; 400.

Table 1. Thermal analysis of 2.

Sample	Stage	TG results temperature range (^0C)	DTA results temperature peak (°C)	Weight loss (%) Found/Calculated	Evolved moiety
2	I II	180–240 240–340	226.71 282.56	43.684/44.75 44.884/44.75	C6H5CONHCSNH C6H5CONHCSNH

References

1. Xu, X.Y.; Qian, X.H.; Li, Z.; Huang, Q.C.; Chen, G. J. Fluorine Chem. 2003, 121, 51-54.

2. Zhou, W.Q.; Yang, W.; Qiu, L.H.; Zhang, Y.; Yu, Z.F. J. Mol. Struct. 2005, 749, 89-95.

3. Arslan, H.; Külcü, N.; Flörke, U. Spectrochim. Acta Pt. A 2006, 64, 1065–1071

4. Kodomari, M.; Suzuki, M.; Tanigawa, K.; Aoyama, T. Tetrahedron Lett. 2005, 46, 5841-5843.

5. Binzet, G.; Arslan, H.; Flörke, U.; Külcü, N.; Duran, N. J. Coordination Chem. 2006, 59,
1395–1406.
